070007280 SWEEP LINK ASM TELESCOPE

Sweep Link Assembly Teles
SKU
070007280
This part is a rod assembly having two rod ends, one attached to a tube, the other to a rod. The rod slides into the tube. One rod end connects to the rear pivot connection of the sweep links and the other rod end to the sweep link bracket. The sweep link bracket is adjustable to set the sweep height. The Sweep Link Telescope assembly must be able to expand in length as the sweep runs thru its cycle. There are two of these used per pinspotter, one for each sweep arm assembly
Mer informasjon
SKU 070007280
Color N.A.
Brand QubicaAMF
